| Function: |
| 1.Automatically supply the lower shells |
| 2.Automatically supply the backplane |
| 3.Automatically detect the direction of the lower shells and adjust accordingly |
| 4.Automatically detect the bad marks on backplanes and remove them |
| 5.Automatically cutting the strips and put them into the shells |
| 6.Automatically supply the upper shells |
| 7.Automatically detect the direction of the upper shells and adjust accordingly |
| 8.Automatically detect whether there is a test strip installed in shell |
| 9.Automatically attach the upper shell and press |
|
| Elements standard |
| Track part：Hard chromium plating on 45 steel surface or Aluminum alloy anodizing and sandblasting |
| Important part:Vacuum Heat-treatment SKD11 or SKH9 or Tungsten steel |
| Pneumatic part: Airtac and SMC |
| PLC：Omron |
| Standard part:MISUMI or HIWIN |
|
| Technical data: |
| 1.Model type：Fully enclosed |
| 2.Control and screen：PLC control and touch screen |
| 3.Capacity：more than 2200/hour |
| 4.Activation：95% |
| 5.Rejection rate:<0.3% |
| 6. Bad strips detection rate：100% |
| 7.Cutting precision：±0.05mm |
| 8.Operator：One person |
